Reinventy Shield™
Tactical Edge Super-Node
Technical & Connectivity Overview
What Is Reinventy Shield?
A wearable, IP-67 micro-datacenter that delivers the entire C4ISR chain—Command, Control, Communications, Computers, Intelligence, Surveillance & Reconnaissance—directly on the operator in denied, disconnected or congested environments.
Form-factor (new triple-layer shell)
Inner EMI liner – SLA-printed ESD Resin (carbon-nanotube filled) for RF/EMI attenuation and antistatic protection.
Thermal / fire barrier – investment-cast High-Temp Resin core (HDT > 238 °C) acting as a heat-sink and flame shield.
Outer armour – SLS/MJF Nylon-12 CF (30 % carbon-filled) reinforced with Kevlar® continuous fibres for ballistic-grade impact resistance, vibration damping and radar-absorbing matte finish.
Fan-less, fully sealed, total mass < 800 g,
Cold-start ➜ operational drone link < 90 s.
Fully MOSA/SOSA-aligned, 100 % FOSS / COTS—zero vendor lock-in, fully auditable.
Core Processing – NVIDIA® Jetson Orin NX 16 GB
| Metric | Value |
|---|---|
| AI Compute (INT8) | ≈ 157 TOPS (> 150 TFLOPS equiv.) |
| FP16 / FP32 | 50 TOPS · 7 TFLOPS |
| CPU Complex | 8 × Arm Cortex-A78AE @ 2 GHz |
| Memory | 16 GB LPDDR5 @ 102 GB/s |
| Power Envelope | 15-25 W (software-selectable) |
Implication – Vision AI (YOLO-v8 Tiny > 120 fps), µLLM inference (1.3 B params @ 22 tok s-¹) and multi-sensor SLAM all run locally—no cloud, no latency.
Secure-by-Design, Modular-by-Default
| Layer | Component | Function |
|---|---|---|
| OS / Containers | Ubuntu 22 + Docker Compose | Immutable images; restart-unless-stopped |
| DevSecOps Offline | Gitea + Drone CI/CD | Build → sign → deploy inside air-gap |
| Secrets | HashiCorp Vault | KMS, RBAC, audit |
| User Creds | Vaultwarden | 2-FA password vault |
| Threat Intel | Suricata NIDS · TheHive/Cortex | Realtime detection & automated response |
| FC Link | Isolated MAVLink UART | Hard-separated from userland |
Mission-Adaptive Connectivity Layer
| Domain | Module | Throughput | Emission-Control Logic |
|---|---|---|---|
| LTE / 5G-NR | Quectel RG502 | 3 Gb s-¹ DL · 900 Mb s-¹ UL | Burst-On™ – radio opens < 3 s for packet push, then mutes |
| Starlink Direct-to-Cell | Gen-2 µKu phased array | ~17 Mb s ↕ · 50-70 ms | Low-probability chirp bursts; auto-shutdown |
| Iridium Certus | 9770 modem | 176 kb s ↕ | Fallback auto-dial; AES-GCM |
| Mesh MANET | Silvus SC-4400 | 4×4 MIMO · 20 W PEP | Power throttled to 250 mW when stealth required |
Open → Close → Vanish™ Workflow
| Phase | Trigger | Shield / Swarm Behaviour |
|---|---|---|
| Open | Tasking / payload upload | LTE/SAT on → TLS 1.3 + WireGuard → data burst |
| Close | Transit to AOI | All RF off; dead-reckon GNSS+IMU |
| Vanish | SIGINT threat detected | Switch to LPI/LPD spread-spectrum or full blackout |
| Re-Open | On-target / scheduled slot | Radio burst < 5 s, encrypted telemetry sync, auto-mute |
Duty-cycle RF TX < 1 % ⇒ triangulation virtually impossible.
Unique Capability Set
BioPrint™ dual-layer authentication – 5 µm fingerprint + sebaceous-impedance spectroscopy (0.025 mm nickel filaments).
Edge AI – Vision, µLLM ops-chat, EW/SIGINT pattern-recognition all on Orin NX.
Stealth Swarm Control – native planner for Fenice H-3 wing-body drones (SHADE metamaterial skin).
Plug-and-Fight Modularity – attach new sensors via USB 3.2 / 1 GbE; deploy new functions as containers.
Performance Benchmarks (25 W mode)
| Task | Model | Result |
|---|---|---|
| Object Detection (HD) | YOLO-v8s INT8 | > 120 fps |
| SAR-to-Map Segmentation | UNet-Dynamic FP16 | 45 fps |
| VIO SLAM | ORB-SLAM3 GPU | σ < 1 cm / m |
| µLLM Chat | 1.3 B QLoRA-4bit | 22 tok s-¹ |
Why Shield Is Unmatched Worldwide
> 150 TOPS AI compute in a passively-cooled wearable.
Dual biometric + biochemical ID—no other military device combines both.
DevSecOps air-gap from git push to drone OTA.
Selective-RF connectivity—LTE/5G, Starlink D2C, Iridium, MANET—opening for seconds, then disappearing.
Lifecycle cost ~-60 % vs proprietary prime-contractor kits, thanks to 100 % open architecture.
Key Take-Aways
Deploy autonomy, security, and raw AI power where satellites fall silent.
Time-to-mission cut from hours to minutes.
Future-proof: every upgrade = one more container, not new hardware.
One Shield replaces: ground station, CI/CD server, secrets vault, NIDS, and edge AI node—at the power draw of a rugged laptop.
Reinventy Shield – Wear it. Launch in minutes. Own the battlespace
